샘플 프로그램1：MM_S1_Vis_Basic

   1:  !-------------------------------- ;
   2:  !FUNCTION: trigger Mech-Vision ;
   3:  !project and get vision result ;
   4:  !Mech-Mind, 2023-12-25 ;
   5:  !-------------------------------- ;
   6:   ;
   7:  !set current uframe NO. to 0 ;
   8:  UFRAME_NUM=0 ;
   9:  !set current tool NO. to 1 ;
  10:  UTOOL_NUM=1 ;
  11:  !move to robot home position ;
  12:J P[1] 100% FINE    ;
  13:  !initialize communication ;
  14:  !parameters(initialization is ;
  15:  !required only once) ;
  16:  CALL MM_INIT_SKT('8','127.0.0.1',50000,5) ;
  17:  !move to image-capturing position ;
  18:L P[2] 1000mm/sec FINE    ;
  19:  !trigger NO.1 Mech-Vision project ;
  20:  CALL MM_START_VIS(1,0,2,10) ;
  21:  !get vision result from NO.1 ;
  22:  !Mech-Vision project ;
  23:  CALL MM_GET_VIS(1,51,53) ;
  24:  !check whether vision result has ;
  25:  !been got from Mech-Vision ;
  26:  !successfully ;
  27:  IF R[53]<>1100,JMP LBL[99] ;
  28:  !save first vision point data to ;
  29:  !local variables ;
  30:  CALL MM_GET_POS(1,60,70,80) ;
  31:  !move to intermediate waypoint ;
  32:  !of picking ;
  33:J P[3] 50% CNT100    ;
  34:  !move to approach waypoint ;
  35:  !of picking ;
  36:L PR[60] 1000mm/sec FINE Tool_Offset,PR[1]    ;
  37:  !move to picking waypoint ;
  38:L PR[60] 300mm/sec FINE    ;
  39:  !add object grasping logic here, ;
  40:  !such as "DO[1]=ON" ;
  41:  PAUSE ;
  42:  !move to departure waypoint ;
  43:  !of picking ;
  44:L PR[60] 1000mm/sec FINE Tool_Offset,PR[1]    ;
  45:  !move to intermediate waypoint ;
  46:  !of placing ;
  47:J P[4] 50% CNT100    ;
  48:  !move to approach waypoint ;
  49:  !of placing ;
  50:L P[5] 1000mm/sec FINE Tool_Offset,PR[2]    ;
  51:  !move to placing waypoint ;
  52:L P[5] 300mm/sec FINE    ;
  53:  !add object releasing logic here, ;
  54:  !such as "DO[1]=OFF" ;
  55:  PAUSE ;
  56:  !move to departure waypoint ;
  57:  !of placing ;
  58:L P[5] 1000mm/sec FINE Tool_Offset,PR[2]    ;
  59:  !move back to robot home position ;
  60:J P[1] 100% FINE    ;
  61:  END ;
  62:   ;
  63:  LBL[99:vision error] ;
  64:  !add error handling logic here ;
  65:  !according to different ;
  66:  !error codes ;
  67:  !e.g.: status=1003 means no ;
  68:  !point cloud in ROI ;
  69:  !e.g.: status=1002 means no ;
  70:  !vision results ;
  71:  PAUSE ;
