Typical Case Practices of 3D Measurement and Inspection
Mech-Mind typical case practices are practical application guides derived from numerous successful use cases in various application scenarios. This manual will guide you step by step to easily deploy typical 3D measurement and inspection applications.
Overview of a Typical Application Deployment Process
The solution library of Mech-Mind provides a wealth of typical solutions. You can select suitable typical applications according to application scenarios, and then quickly complete the deployment of 3D measurement and inspection applications.
The following figure shows the general process of typical application deployment.
During the solution design stage, you need to assess the risks a 3D measurement and inspection application might encounter in actual project deployment, then design a solution that meets the project’s requirements.
The deployment of the 3D measurement and inspection solution refers to applying the typical application cases to your actual project according to the solution design, including the entire process from the hardware setup to the final measurement and inspection.
For more information about each stage of application deployment, see Learning Guidance for 3D Measurement and Inspection.
Guidance on Typical Case Practices
Pin Height Measurement
|
Measures and inspects the height of connector pins relative to the base plane.
|
Connector Pin Position Inspection
|
Measures and inspects the position of connector pins relative to reference lines.
|
Connector Pin Inspection (Height & Position)
|
Measures and inspects the height and position of connector pins in the target object reference frame.
|
Smartphone Midplate Flatness Measurement
|
Measures the flatness of smartphone midplates.
|
Dimensional Measurement of Refractory Bricks
|
Measures and inspects the height and length of refractory bricks.
|
Defect Inspection for Brake Pads (Blob Analysis)
|
Uses the blob analysis method to detect defects such as depressions and protrusions on the surface of brake pads.
|
Offline Bead Inspection
|
Measures and inspects the cross-sectional area, height, width, and offset of adhesive beads.
|
Clip Presence Inspection
|
Inspects the presence of clips to determine whether the cable-securing devices are installed correctly.
|
