Input/Output of Steps

You are currently viewing the documentation for version 2.1.2. To access documentation for other versions, click the "Switch Version" button located in the upper-right corner of the page.

■ To use the latest version, visit the Mech-Mind Download Center to download it.

■ If you're unsure about the version of the product you are using, please contact Mech-Mind Technical Support for assistance.

The input/output ports of each Step are on the top or at the bottom of the Step, as shown below, where 1 represents the input ports, and 2 the output ports.

input

You can view the detailed description of a Step port by hovering the mouse over it.

output
