Ethernet Cable
Physical Specifications
Model |
Straight connector
|
Right-angle connector
|
|---|---|---|
Color |
Black |
|
Jacket material |
PVC |
|
Outer diameter |
6.5 mm |
|
Minimum bending radius |
≥52 mm |
|
P1 connector |
M16, straight connector or right-angle connector |
|
P2 connector |
RJ45 |
|
Cable standard |
Cat 5e |
|
Bending cycles |
>=10 million |
|
Torsion cycles |
>=3 million |
|
Safety |
RoHS: compliant
|
|
Applicable Laser Profiler Models |
LNX-7030-GL LNX-7045-GL LNX-7080-GL LNX-7150-GL LNX-7300-GL LNX-7600-GL |
|
Dimensions
Unit: mm
|
CBLLNX-ETH |
|
CBLLNX-ETH-LU |
| Model | L | Tolerance |
|---|---|---|
CBLLNX-ETH-5M |
5 m |
± 40 mm |
CBLLNX-ETH-10M |
10 m |
± 80 mm |
CBLLNX-ETH-20M |
20 m |
± 150 mm |
CBLLNX-ETH-30M |
30 m |
± 200 mm |
CBLLNX-ETH-5M-LU |
5 m |
± 40 mm |
CBLLNX-ETH-10M-LU |
10 m |
± 80 mm |
CBLLNX-ETH-20M-LU |
20 m |
± 150 mm |
CBLLNX-ETH-30M-LU |
30 m |
± 200 mm |
