DC Power & IO Extension Cable

You are currently viewing the documentation for a pre-release version (2.6.1). To access documentation for other versions, click the "Switch Version" button located in the upper-right corner of the page.

■ If you're unsure about the version of the product you are using, please contact Mech-Mind Technical Support for assistance.

Physical Specifications

Model

CBLLNX-PWR-IOE-EXT-5M
CBLLNX-PWR-IOE-EXT-10M

Color

Black

Jacket material

PVC

Outer diameter

11.5 mm

Minimum bending radius

92 mm

Connectors

M16, straight connector

Bending cycles

>=10 million

Torsion cycles

>=3 million

Safety

RoHS: compliant
Flame retardant rating of plastic materials: 94-V0

Applicable Laser Profiler Models

LNX-7030-GL

LNX-7045-GL

LNX-7080-GL

LNX-7150-GL

LNX-7300-GL

LNX-7600-GL

Dimensions

Unit: mm

dc power io cable extension dimension
Model L Tolerance

CBLLNX-PWR-IOE-EXT-5M

5 m

± 40 mm

CBLLNX-PWR-IOE-EXT-10M

10 m

± 80 mm

Connectors

cable extension p1

cable extension p2

P1 Mating Face

P2 Mating Face
P1 P2 Definition

L

L

-V (0V DC)

A

A

+V (24V DC)

G

G

Trigger_In-

J

J

Trigger_In+

E

E

Out_1+

C

C

Out_1-

M

M

CONFIG_IO+

N

N

CONFIG_IO-

O

O

Encoder_B+

P

P

Encoder_B-

S

S

Encoder_A+

R

R

Encoder_A-

T

T

Out_2+

U

U

Out_2-
