Ethernet Cable (M12-A Connector)
Physical Specifications
Model |
CBL-ETH-5M CBL-ETH-15M |
|---|---|
Color |
Black |
Outer jacket material |
PVC |
Cable standard |
Cat 5e |
Outer diameter |
6.5 ± 0.2mm |
Connectors |
M12-A, straight-angle, 8 pins RJ45 |
Minimum static bend radius |
26mm |
Minimum dynamic bend radius |
52mm |
Safety |
Compliant with RoHS Flammability rating of plastic materials: V-0 Cable flammability rating: VW-1 |
Drag chain test |
Cycles: ＞ 10 million |
Torsion test |
Cycles: ≥ 3 million |
Compatible camera models |
AIC-Lite-050M-08A-W-GL AIC-Lite-050M-16A-W-GL AIC-Lite-050C-08A-W-GL |
Connectors
|
|
M12-A connector |
RJ45 connector |
| Function | M12-A connector pin | RJ45 connector pin |
|---|---|---|
MD0_N |
6 |
2 |
MD0_P |
4 |
1 |
MD1_N |
8 |
6 |
MD1_P |
5 |
3 |
MD2_N |
2 |
5 |
MD2_P |
3 |
4 |
MD3_N |
7 |
8 |
MD3_P |
1 |
7 |
