Save Data
You can save the acquired 2D image, depth map, point cloud, and the virtual device file.
Save Acquired Data
You can save the acquired 2D image, depth map, and point cloud to local manually or automatically.
Please follow these steps to save acquired data:
-
In the data display area, select Manual save or Auto save from the drop-down list.
If Auto save is selected, the software automatically enables the data save switch. After data acquisition starts, the software automatically saves the acquired data.
-
Click the Settings button to open the Save Data window.
-
Select the data types to be saved:
-
To use the saved data in Mech-MSR and Mech-Vision, select the checkbox before Data immediately readable by Mech-MSR and Mech-Vision. The saved data can be read in the Structured-Light 3D Camera Step in Mech-MSR and the Virtual Mode in the Capture Images from Camera Step in Mech-Vision.
-
To save the 2D image, depth map, or point cloud separately, select the checkbox before Customize and then select the data type that you need to save. For detailed descriptions, please refer to Data Types and Formats.
-
-
Click
to the right of Save to to select the folder for saving the data. -
When Auto save is selected, set the Auto save count parameter. The software stops auto saving when the number of successful saves reaches the set value.
-
Click Confirm to save the setting.
-
Acquire and save data:
-
When Manual save is selected, click the
button to acquire data once, and then click the
button to save the acquired data. -
When Auto save is selected, enable the data save switch, and then click the
button to acquire data continuously. The software automatically saves the acquired data to local.
-
Data Types and Formats
When saving the data, you can select the file format to be saved, as well as the data structure, color, and reference frame of the point cloud.
-
2D image: can be saved in the PNG (.png) or JPEG (.jpg) format.
-
Depth map: can be saved in the PNG (.png) or TIFF (.tiff) format.
-
Point cloud: can select the file format, data structure, color, and reference frame to be saved.
Format
-
PLY (.ply): Supports binary and ASCII formats
-
PCD (.pcd): Supports binary and ASCII formats
-
CSV (.csv)
Data structure
-
Organized: The point cloud resembles a two-dimensional matrix, which corresponds to the actual spatial relationship between points.
-
Unorganized: The point cloud resembles a one-dimensional list.
Color
-
Jet
-
Grayscale
-
Jet + intensity
-
Untextured
-
Textured
Reference frame
-
Device: Saves the point cloud in the camera reference frame.
-
Custom: Saves the point cloud in the custom reference frame.
-
Save Virtual Device File
Virtual devices reproduce the previously acquired data, thus helping Technical Support locate the cause of a problem. To save a virtual device, click in the menu bar.
|
