Sensor-Head-to-Controller Cable

You are currently viewing the documentation for version 2.4.1. To access documentation for other versions, click the "Switch Version" button located in the upper-right corner of the page.

■ To use the latest version, visit the Mech-Mind Download Center to download it.

■ If you're unsure about the version of the product you are using, please contact Mech-Mind Technical Support for assistance.

Physical Specifications

Color

Black

Jacket material

PVC

Outer diameter

6.6 mm

Connector

M12, 12 pins

Static bend radius

50 mm

Rated voltage

30 VDC

IP rating

IP67

Safety

RoHS: compliant
Flame retardant rating of plastic materials: V-0
Flame retardant rating of cable body: VW-1

Mobile tow chain test

Bend radius: 50 mm
Traversing distance: 1000 mm
Speed: 30 bends/min
Bend cycles: ≥ 10 million

Torsion test

Angle: ± 180°
Length: 1000 mm
Speed: 30 twists/min
Torsion cycles: ≥ 3 million

Can be used with

Sensor head: LNX-8030-GL, LNX-8080-GL, LNX-8300-GL, LNX-7530-GL, LNX-7580-GL, LNX-75150-GL, LNX-75300-GL
Controller: LNX-8000C-GL, LNX-7500C-GL

Dimensions

Unit: mm

sensor head to controller cable dimension
Model L

CBL-H2C-5M-LU

5 m

CBL-H2C-10M-LU

10 m

CBL-H2C-15M-LU

15 m

CBL-H2C-20M-LU

20 m
