DC Power Cable

You are currently viewing the documentation for the latest version (2.5.1). To access a different version, click the "Switch version" button located in the upper-right corner of the page.

■ If you are not sure which version of the product you are currently using, please feel free to contact Mech-Mind Technical Support.

Physical Specifications

Model

Straight connector

Right-angle connector

CBL-PWR-5M
CBL-PWR-10M
CBL-PWR-15M
CBL-PWR-20M
CBL-PWR-30M

CBL-PWR-5M-LU
CBL-PWR-10M-LU
CBL-PWR-15M-LU
CBL-PWR-20M-LU
CBL-PWR-30M-LU

Color

Black

Jacket material

PVC

Outer diameter

5.6 ± 0.15 mm

Connectors

M12-A, straight or right-angle, 4 pins
Pigtail

Wire gauge

22AWG

Minimum static bend radius

22.4 mm

Minimum dynamic bend radius

44.8 mm

Safety

RoHS: compliant
Flame retardant rating of plastic materials: V-0
Flame retardant rating of cable body: VW-1

Mobile tow chain test

Bend cycles: > 10 million

Torsion test

Torsion cycles: ≥ 3 million

Can be used with

DEEP-GL

Log S
Log M

LSR S-GL

LSR L-GL

LSR XL-GL

NANO-GL

NANO ULTRA-GL

PRO XS-GL

PRO S-GL

PRO M-GL

UHP-140-GL

Dimensions

Unit: mm

power cable angled
power cable straight
Model L Tolerance

CBL-PWR-5M / CBL-PWR-5M-LU

5 m

± 40 mm

CBL-PWR-10M / CBL-PWR-10M-LU

10 m

± 80 mm

CBL-PWR-15M / CBL-PWR-15M-LU

15 m

± 100 mm

CBL-PWR-20M / CBL-PWR-20M-LU

20 m

± 150 mm

CBL-PWR-30M / CBL-PWR-30M-LU

30 m

± 200 mm

Connectors

power cable m12

M12-A connector

Function M12-A connector pin Pigtail wire color

GND

1

Black

GND

2

Black

24 VDC

3

Red

24 VDC

4

Red

PE

-

Yellow-green
