Ethernet Cable
Physical Specifications
Model |
Straight connector |
Right-angle connector |
|---|---|---|
CBL-ETH-5M
|
CBL-ETH-5M-LU
|
|
Color |
Black |
|
Jacket material |
PVC |
|
Cable standard |
Cat 5e |
|
Outer diameter |
6.5 ± 0.2 mm |
|
Connectors |
M12-A, straight or right-angle, 8 pins
|
|
Minimum static bend radius |
26 mm |
|
Minimum dynamic bend radius |
52 mm |
|
Safety |
RoHS: compliant
|
|
Mobile tow chain test |
Bend cycles: ＞ 10 million |
|
Torsion test |
Torsion cycles: ≥ 3 million |
|
Can be used with |
DEEP-GL Log S
LSR S-GL LSR L-GL LSR XL-GL |
NANO-GL NANO ULTRA-GL PRO XS-GL PRO S-GL PRO M-GL UHP-140-GL |
Dimensions
Unit: mm
| Model | L | Tolerance |
|---|---|---|
CBL-ETH-5M / CBL-ETH-5M-LU |
5 m |
± 40 mm |
CBL-ETH-10M / CBL-ETH-10M-LU |
10 m |
± 80 mm |
CBL-ETH-15M / CBL-ETH-15M-LU |
15 m |
± 100 mm |
CBL-ETH-20M / CBL-ETH-20M-LU |
20 m |
± 150 mm |
CBL-ETH-30M / CBL-ETH-30M-LU |
30 m |
± 200 mm |
Connectors
|
|
M12-A connector |
RJ45 connector |
| Function | M12-A connector pin | RJ45 connector pin |
|---|---|---|
MD0_N |
6 |
2 |
MD0_P |
4 |
1 |
MD1_N |
8 |
6 |
MD1_P |
5 |
3 |
MD2_N |
2 |
5 |
MD2_P |
3 |
4 |
MD3_N |
7 |
8 |
MD3_P |
1 |
7 |
