Technical Specifications
Technical Specifications
Model |
Mech-Eye GL2D-080 |
Mech-Eye GL2D-110 |
Mech-Eye GL2D-150 |
|
|---|---|---|---|---|
Performance |
Resolution |
1.6MP |
||
Light source |
White, red, green, blue (switchable) |
|||
Working distance |
80 ± 20 mm |
110 ± 20 mm |
150 ± 30 mm |
|
Field of view (per camera) |
89 × 71 mm |
120 × 80 mm |
183 × 128 mm |
|
Imaging resolution |
FOV (near): approx. 330 DPI |
|||
FOV (far): approx. 200 DPI |
||||
Detection accuracy |
FOV (near): <0.2 mm |
|||
FOV (far): <0.37 mm |
||||
Dispensing tilt angle |
<25° |
|||
Dispensing speed |
Maximum: 1500 mm/s (requires a high-performance IPC) |
|||
Detection result latency |
<2 s |
|||
Trigger mode |
Software trigger + external hardware trigger |
|||
Supported bead types |
Linear bead, dot bead |
|||
Supported inspection types |
Missing bead, bead break, too thick, too thin, bead offset, etc. |
|||
Electrical characteristics |
Data interface |
Gigabit Ethernet (1000 Mbit/s) |
||
Trigger I/O |
Typical: 12 VDC Supported range: 9 to 24 VDC |
|||
Supply voltage |
24 VDC |
|||
Typical power consumption (room temperature, 24 VDC) |
Red: 26 W Green: 33 W Blue: 36 W White: 29 W |
|||
Mechanical characteristics |
Dimensions |
Diameter: 152 mm Thickness: 51 mm Center hole diameter: 44 mm |
||
Weight |
Approx. 1.5 kg (excluding cables) |
|||
Temperature |
Operating temperature: 0 to 45 °C Storage temperature: -20 to 60 °C |
|||
Humidity |
20 to 80%RH, non-condensing |
|||
IP rating |
IP65, compliant with IEC 60529 |
|||
General specifications |
Software |
Mech-GlueCheck |
||
Operating system |
Windows 10 (64-bit) |
|||
Communication method |
TCP/IP, EtherNet/IP, PROFINET, etc. |
|||
MES integration |
Supports integration with MES (manufacturing execution systems) |
|||
