网线
物理参数
型号 |
直头 |
弯头 |
|---|---|---|
CBL-ETH-5M CBL-ETH-10M CBL-ETH-15M CBL-ETH-20M CBL-ETH-30M |
CBL-ETH-5M-LU CBL-ETH-10M-LU CBL-ETH-15M-LU CBL-ETH-20M-LU CBL-ETH-30M-LU |
|
颜色 |
黑 |
|
外护套材质 |
PVC |
|
线缆标准 |
Cat 5e |
|
外径 |
6.5 ± 0.2mm |
|
接头 |
M12-A，直头或弯头，8针脚 RJ45 |
|
最小静态弯曲半径 |
26mm |
|
最小动态弯曲半径 |
52mm |
|
安全性 |
符合RoHS标准 塑料材料阻燃等级：V-0 线缆本体阻燃等级：VW-1 |
|
拖链测试 |
次数：＞ 1000万 |
|
扭转测试 |
次数：≥ 300万 |
|
适用相机型号 |
DEEP Log S Log M LSR S LSR L LSR XL |
NANO NANO ULTRA PRO XS PRO S PRO M UHP-140 Welding |
尺寸
单位：mm
| 型号 | L | 公差 |
|---|---|---|
CBL-ETH-5M / CBL-ETH-5M-LU |
5m |
±40mm |
CBL-ETH-10M / CBL-ETH-10M-LU |
10m |
±80mm |
CBL-ETH-15M / CBL-ETH-15M-LU |
15m |
±100mm |
CBL-ETH-20M / CBL-ETH-20M-LU |
20m |
±150mm |
CBL-ETH-30M / CBL-ETH-30M-LU |
30m |
±200mm |
接头
|
|
M12-A接头 |
RJ45接头 |
| 功能 | M12-A接头针脚 | RJ45接头针脚 |
|---|---|---|
MD0_N |
6 |
2 |
MD0_P |
4 |
1 |
MD1_N |
8 |
6 |
MD1_P |
5 |
3 |
MD2_N |
2 |
5 |
MD2_P |
3 |
4 |
MD3_N |
7 |
8 |
MD3_P |
1 |
7 |
